MIL-C-684D(MU)
4 . 5 . 2 L o t i d e n t i f i c a t i o n . -Each lot of cups shall be identified as
to type, caliber, and model as well as with a lot number and the supplier's
identification as assigned by the procuringactivity.
4.5.3 Examination. -Examination for major and minor defects shall be
performed on a class basis in accordance with the classification of defects,
Table II, using applicable sampling plan and acceptance criteria of MIL-STD-105.
The Acceptable Quality Level (AQL) for the major class shall be 0.25 percent.
and the AQL for the minor class shall be 2.50 percent. All nonconforming
components shall be rejected.
4.5.3.1 Classification of defects. - The classification of defects shall
as specified in Table II.
Table II
Defect
Method of Inspection
MAJOR
101.
Defective cladding
visual
102.
Improperly formed or mutilated
Visual
103
Laminations or laps
visual
104.
Scratches
visual
105
Cladding thickness
Gage
106.
Outside diameter
Gage
107.
Base thickness
Gage
108.
Wall thickness
Gage
109.
Wall thickness variation
Gage
110.
Wall height variation
Gage
111.
Weight
scale
MINOR
201.
O i l , grease, dirt
Visual
202.
Dents or bent edges
visual
203.
Oxidation
Visual
SPECIAL
301.
Absence of neutral soap film
Certification
Dichromate residue
302.
Certification
S e e 3.7.1
NOTE: Refer to applicable gliding metal clad steel cup section of MIL-STD-1232
for visual defect standards for visual defects listed in Table II.
