MIL-DTL-1394G(AR)
3.5 Pellet weight. The total dry weight of the primer mix shall be as specified on drawing
7548066.
3.6 Electric primer sensitivity. The primer shall function when energized by a 10 microsecond
discharge from a 2 microfarad condenser charged at 160 volts DC.
3.7 Electric primer time. The primer time shall not exceed 300 microseconds when energized by
a 10 microsecond discharge pulse from a 2 microfarad condenser charged at 160 volts DC.
3.8 Action time. The action time of the test cartridge shall be as specified on drawing 7548066.
3.9 Function and casualty. The primer shall function without casualty in the test cartridge (see
Table VII).
3.10 Workmanship. All parts and assemblies shall be fabricated, loaded, and assembled in a
thorough workmanlike manner. They shall be clean and free of burrs, sharp edges, cracks, scratches,
dents, folds, wrinkles, buckles, dirt, grease, oil, rust, and other foreign matter. Exterior surface coatings
shall be continuous; however, light scratches not exposing base material may be permitted.
4. VERIFICATION
TABLE I. Requirement/verification cross reference matrix
METHOD OF VERIFICATION
CLASSES OF VERIFICATION
N/A - Not applicable
A - First article
1 - Analysis
B - Conformance
2 - Demonstration
3 - Examination
4 - Test
Section 3 Requirement
Verification Methods
Verification
Section 4
Class
Method
N/A
1
2
3
4
A
B
3.1
First article
X
X
X
4.2
3.2
Parts and subassemblies
X
X
X
Table IV
3.3
Insulation Strength
X
X
X
4.4.1
3.4
Electrical resistance
X
X
X
4.4.2
3.5
Pellet weight
X
X
X
4.4.3
3.6
Electric primer sensitivity
X
X
X
4.4.4
3.7
Electric primer time
X
X
X
4.4.5
3.8
Action time
X
X
X
4.4.6
3.9
Function and casualty
X
X
X
4.4.7
3.10
Workmanship
X
X
X
Table IV
4.1 Classification of inspection. The inspection requirements specified herein are classified as
follows:
a. First article inspection (see 4.2)
b. Conformance inspection (see 4.3)
4.2 First article inspection. When specified, a sample of 2000 M52 primers and primer
components as identified in Table II shall be subjected to first article verification inspections and tests
with quantities in accordance with Table II and Table IV.
3
