MIL-DTL-48623A (AR)
Table III. Conformance tests
DRAWING
NUMBER
CARTRIDGE, CALIBER .50, BLANK, M1A1
9326760
CONFORMANCE
INSPECTION
CRITERIA
REQUIREMENT
CLASSIFICATION
EXAMINATION OR TEST
METHOD
PARAGRAPH
REFERENCE
QTY
Ac
Re
Critical
None defined
Major
101
Function and casualty 5/, 6/
a. Ambient
300
TableV
3.10
4.5.5
b. 0 ºF
300
TableV
3.10
4.5.5
c. +125 ºF
300
TableV
3.10
4.5.5
102
Residual stress
50
3/
3.5
4.5.1
103
Cyclic rate
1/
4/
3.11
4.5.6
104
Waterproof
20
2/
3.9
4.5.8
105
Screen perforation
50
3/
3.6
4.5.2
Minor
None defined
Notes:
1/. These tests to be performed concurrently with the function and casualty test.
2/ Failure of nine or more cartridges to comply with the applicable requirement shall be
cause for rejection of lot. If more than four, but less than nine cartridges fail in the first
test, a second sample consisting of double the number of cartridges in the first sample
shall be tested. The lot shall be rejected if, in the combined first and second sample,
nine or more cartridges fail to comply with the applicable requirements.
3/ Failure of two or more cartridges to comply with the applicable requirement shall be
cause for the rejection of the lot. If one cartridge fails in the first test, a second sample
consisting of double the number of cartridges in the first sample shall be tested. If any
failing cartridges are found in the second sample, the lot shall be rejected.
4/ The cycle rate shall be determined during the firing of the function and casualty test.
Failure of any burst to comply with the applicable requirement shall be cause for
rejection of the lot subject to the testing of a second sample consisting of double the
number of cartridges in the first sample. Failure of any burst in the second sample to
comply with the applicable requirement shall be cause for rejection of the lot. The
second sample shall be fired in the type of weapon in which the failure occurred.
8
