4.4.2.2 AQL's.-The following AQL's are assigned to major and minor defects:
a.
Individual:
Major
0.25%
Minor
0.40%
b.
Class basis:
Major
1.50%
2.50%
Minor
c.
Individual defects associated with the class basis:
0.40%
Major
The classification of defects shall
4.4.3 Classification of defects
be as follows: (see 6.6)
4.4.3.1 Body (See Dwg. D7258866, a detail of Dwg. D7258864).
Categories and Defects
Method of Inspection
Critical:
None defined.
Major:
Pitch diameter (P.D.), external thread ----------------
Gage
101.
P.D., internal thread ----------------------------------
102.
Gage
Position, P.D., internal thread with datum surfaces ---
103.
Gage
Position, spherical surface, with datum surfaces ------
Gage
104.
105.
Depth to top of precision ball ------------------------
Gage
106.
Depth to rotor detent spring groove -------------------
Gage
107.
Diameter, internal cavity rear of rotor detent
spring groove ---------------------------------
Gage
Diameter, firing pin guide hole -----------------------
108.
Gage
Position, firing pin guide hole with datum surfaces ---
Gage
109.
Break, perimeter of firing pin hole, max. -------------
Gage
110.
Length, base to shoulder ------------------------------
111.
Gage
Depth to end of full internal thread, min, ------------
Gage
112.
Foreign matter ----------------------------------------
113.
Visual
114.
Diameter, rotor detent spring groove ------------------
Gage
Minor:
Major diameter, external thread -----------------------
201.
Gage
202.
Minor diameter, internal thread ----------------------
Gage
203.
Profile, shoulder to nose, except tapered surface
forward of crimping groove --------------------------
Gage
204.
Runout, body taper with datum surfaces ----------------
Gage
205.
Width, rotor detent spring groove ---------------------
Gage
5
