MIL-F-46579D
4.4.3.1 (Cont)
Method of Inspection
Categories and Defects
Minor: (Cont)
206. Diameter, thread relief at shoulder and base --------
Gage
207. Width, thread relief at base; max. ------------------
Gage
208. Width, thread relief at shoulder, max. --------------
Gage
209. Wall thickness variation, rotor detent spring
Gage
groove, max.
210. Internal thread relief missing ----------------------
Visual
Visual/Feel
211. Finish, interior
Visual/Feel
212. Sharp corner or edge
4.4.3.2 Nose cap (See Dw g. C7258867, a detail of Dwg. D7258864).
Method of Inspection
Categories and Defects
None defined.
Critical:
Major:
Gage
Thickness, datum area
101.
Depth, to spherical surface ------------------------- Gage
102.
Gage
Length, crimping lip, min.
103.
Visual
Foreign matter
104.
Minor:
Gage
201.
Length, crimping lip, max.
202.
Angle, crimping lip with conical surface ------------
Gage
Inside diameter, crimping lip -----------------------
Gage
203.
Gage
Profile, closed end
204.
Thickness, except datum area ------------------------
Gage
205.
Burr or sliver, inside edge of crimping lip ---------
Visual/Feel
206.
Firing pin (See Dwg. C7258868. a detail of Dwg. D7258864).
4.4.3.3
Method of Inspection
Categories and Defects
None defined.
Critical:
Major:
Total length
Gage
101.
Gage
Thickness, flange
102.
Diameter, body
Gage
103.
Profile, point
Gage
104.
Damage
Visual
105.
Foreign matter
Visual
106.
6
