MIL-F-46579D
4.4.3.3 (Cont)
Method of Inspection
Categories and Defects
Minor:
Gage
Profile, head
201.
Gage
Diameter, flange
202.
Gage
Length, flange to shoulder
203.
Radius, at intersection of flange and body, max. ----- Gage
204.
Visual/Feel
Finish
205.
Visual/Feel
Burr or sharp edge
206.
4.4.3.4 Rotor detent spring (See Dwg. C7258869, a detail of Dwg. D7258864).
Method of Inspection
Categories and Defects
Critical:
None defined.
Major:
Inside diameter (I.D.), max. -------------------------
Gage
101.
Width, at center line of throat radius ---------------
Gage
102.
Deformity (excluding out of flatness) ----------------
Visual
103.
Foreign matter, including corrosion ------------------
Visual
104.
Visual/Feel
Burr or sharp edge
105.
Minor:
Gage
201.
Outside diameter
Position, I.D. with datum surface --------------------
Gage
202.
203.
Thickness, min., and including out of flatness, max. -
Gage
Width, across opening
204.
Gage
Visual
Radius, opposite open end
205.
Visual/Feel
Finish
206.
Radii, open end
Visual
207.
Rotor (see Dwg. D7258870, a detail of Dwg. D7258864).
4.4.3.5
Method of Inspection
Categories and Defects
Critical:
None defined.
Major:
Gage
101.
Spherical diameter
Diameter, detonator cavity
Gage
102.
Gage
Depth, detonator cavity
103.
Diameter, detent spring seat -------------------------
Gage
104.
105.
Height, detent spring seat to spherical surface ------
Gage
Radius, at perimeter of detonator cavity, max. -------
Gage
106.
Position, detonator cavity with datum surface --------
Gage
107.
Gage
Location, large flat
108.
Damage
Visual
109.
Foreign matter
Visual
110.
Angle, detent spring seat with large flat ------------
Gage
111.
Gage
Diameter, flash hole
112.
7
