MIL-DTL-12779D
TABLE V. Defect inspections Continued.
Classification.
Examination or Test 1/
Conformance
Requirement
Inspection
Criteria 2/
Paragraph
Method
Reference
Minor
201
Discolored, dirty, oily,
Level II
3.3
Visual
smeared (cartridge) (1)
202
Round head (case) (4)
Level II
3.3
Visual
203
Dent (case) (5)
Level II
3.3
Visual
204
Split case - between mouth
Level II
3.3
Visual
and top of wad (6)
205
Perforated case Between
Level II
3.3
Visual
mouth and top of wad (7)
206
Draw scratch (case) (8)
Level II
3.3
Visual
207
Scratch (9)
Level II
3.3
Visual
208
Beveled underside of head
Level II
3.3
Visual
(case) (10)
209
Scaly metal (case) (11)
Level II
3.3
Visual
210
No chamfer on head (rim)
Level II
3.3
Visual
(12)
211
Wrinkle (case) (13)
Level II
3.3
Visual
212
Bulge (case) (14)
Level II
3.3
Visual
213
Illegible , missing, or
Level II
3.3
Visual
incorrect head stamp (15)
214
Defective head (case) (16)
Level II
3.3
Visual
215
Nicked or dented primer (28)
Level II
3.3
Visual
216
No waterproofing material
Level II
3.3
Visual
(primer pocket joint) (29)
217
Fold case
Level II
3.3
Visual
218
Wad and joint between case
Level II
3.3
Visual
and wad not completely
covered by lacquer
219
Workmanship (see 3.11 and
Level II
3.3
Visual
4.5.8) 3/
Notes:
1/ Numbers in parenthesis after defects description refer to visual standards for defects 1
through 29 in MIL-STD-636 (NATO, 9mm and Caliber .45 Section). While no photographs of
blank line throwing cartridges are included in this Standard, the cartridge case defects illustrated
in Caliber .45 Section can be used. In the event of conflict between Table V of this
specification and MIL-STD-636, as to defect classification, the classification specified in Table
V shall apply.
10
