MIL-DTL-12779D
4.3.1 First article quantity. The first article sample shall consist of the following item in
the sample quantity as indicated in Table II.
TABLE II. First article quantity.
Part Description
Drawings
Quantity
Cartridge, Caliber .45, Blank,
500
7553068
Line, Throwing M32
Empty Primed Cartridge cases
7553068
800
(no propellant)
Case
10524075
5 1/
Notes:
1/ Per station per machine. Each station of each machine is
considered a separate manufacturing process.
4.3.2 First article rejection. If any assembly, component or test specimen fails to comply
with requirements, the first article sample shall be rejected (see 6.7).
4.4 Conformance inspection.
4.4.1 Inspection lot formation. Lot formation shall be in accordance with MIL-STD-
1168. Unless otherwise specified, component parts shall be homogenous, inspected and tested.
The cartridge lot shall contain:
a. Cartridge cases from one unchanged process and from one manufacturer
b. Primers from one lot interfix number and from one manufacturer
c. Propellant from no more than two lot numbers and from one manufacturer
4.4.2 Classification of characteristics.
a. Sampling requirements. Inspection sampling requirements for critical, major and minor
characteristics are defined in MIL-STD-1916. Unless specified otherwise, Inspection Level VII
in addition to 100% inspection shall be used for all characteristics defined as Critical, Inspection
Level IV shall be used for all characteristics defined as Majors and Inspection Level II for all
Minor characteristics.
b. Inspection. Conformance inspection shall be performed in accordance with Table IV,
Table V, and Table VI. For all conformance inspections the same sample specimen may be used
for all non-destructive examinations or tests.
6
