MIL-DTL-1318C (AR)
Table V. Conformance inspections - Continued
DRAWING NUMBER
CARTRIDGE, CALIBER .50, TRACER, M17
7672165
INSPECTION
REQUIREMENT
CONFORMANCE
METHOD
CLASSIFICATION
EXAMINATION OR TEST 1/
CRITERIA 3/
PARAGRAPH
2/ REFERENCE
3.3
117
Cartridge profile failure
Gage
requiring more than 80 lbs dead
weight to insert profile and
alignment gage
118
Diameter of extractor groove,
3.3
Gage
maximum
119
Diameter of head, maximum
3.3
Gage
120
Thickness of head, maximum
3.3
Gage
121
Distance to shoulder datum
3.3
Gage
122
Depth of primer
3.1
Gage
123
Missing lead slug in bullet 5/
3.3
Gage
Minor
201
Discolored, Dirty, oily, or
3.3
Visual
smeared (waterproofing) (1)
202
Dented case (5)
3.3
Visual
203
Draw scratch in case (8)
3.3
Visual
204
Scratch in case (9)
3.3
Visual
205
Scaly metal on case (12)
3.3
Visual
206
Fold, wrinkle buckle, or bulge in
3.3
Visual
case (14, 15, 16, 17)
207
Head stamp missing or illegible
3.3
Visual
(18)
208
Defective head (19)
3.3
Visual
209
Defective mouth (case) (20)
3.3
Visual
210
Dented bullet (22)
3.3
Visual
211
Bullet scratched (23)
3.3
Visual
212
Scaly metal (bullet) (27)
3.3
Visual
213
Upset (crooked) point (28)
3.3
Visual
214
Exposed steel (clad jacket)
3.3
Visual
(bullet) (29)
215
Blunt point (bullet) (30)
3.3
Visual
216
Defective cannelure (31)
3.3
Visual
217
Nicked or dented primer (36)
3.3
Visual
12
