MIL-P-50601A(MU)
4.4.4 (Cont)
Table I
Sample
Req.
Size
Item
Para.
Test
Assemblies, painted
315
3.5
Band tightness
Assemblies, unpainted
315
Soundness verification
(see 4.5.5)
3.6
Automatic inspection
--
PCS No. 1 (see 4.5.3)
effectiveness
Assemblies, painted
50
Projectile nose torque
3.7
Phosphate coating
3 standard
panels, TT-C-490
(appearance and weight)
3.8.1
Assemblies,
painted,
13
Paint adhesion
TT-C-490
3.8.2
Assemblies,
painted
Corrosion resistance
32
3.8.3
Assemblies,
painted
250
Metal parts security
3.9
If two or more units of the sample have an average radial void, between
the seated band and the band seat, greater than 0.004 inch, the lot shall
be rejected. If one unit of the sample has an average radial void greater
than 0.004 inch, a second sample consisting of the same number of units as
specified for the first sample shall be tested. If, in the accumulated
samples, two or more units have an average radial void greater than 0.004
inch, the lot shall be rejected.
Rejection of one or more units of the sample by the flaw detector in the
test for body metal soundness shall be cause for rejection of the lot.
Failure of the flaw detector to reject PCS No. 1 shall be cause for rejec-
tion of all assemblies inspected for "soundness" since the preceding test
and shall require requalification of the equipment for automatic inspection.
(see 4.5.3)
Projectile nose torque. -Failure of one or more of the sample projectiles
to comply with the specified torque requirement shall be cause for rejection
of the lot.
Failure of the phosphate coating on the standard panels to comply with the
applicable requirements, shall cause rejection of all production assemblies
phosphate since the preceding test.
If two or more units of the sample fail to comply with the requirement
for paint adhesion, the lot shall be rejected. If one unit of the sample
fails to comply with the requirement, a second sample consisting of the same
number of units as specified for the first sample shall be tested. If in
the accumulated samples, two or more units fail to comply with the require-
ment for paint adhesion, the lot shall be rejected.
10
