MIL-P-50601A(MU)
4.4.3.2 Nose (see Dwg. C1054266O)
Categories and Defects
Method of Inspection
Critical:
None defined.
Major:
Diameter, ogive at shoulder, min. -----------------
101.
Gage
Length, nose to shoulder, max. -------- ------------
102.
Gage
103.
Pitch diameter of threads
Gage
104.
Major diameter of threads
Gage
105.
Runout, ogive surface with thread
including perpendicularity with shoulder
Gage
Minor:
201.
Diameter, ogive at shoulder, max.
Gage
202.
Length, nose to shoulder, min.
Gage
Diameter, cylindrical surface rear of threads -----
203.
Gage
Length, rear of thread to shoulder face -----------
204.
Gage
205.
Finish
Visual
Foreign matter -------- -------- ---------------- ----
206.
Visual
207.
Mutilated
Visual
4.4.3.3 Body prior to banding (see Dwg. D10542659)
Critical:
None defined.
Major:
Length, mouth to rear of rotating band seat -------
101.
Gage
Knurling missing or incomplete --------------------
102.
Visual
Foreign matter in rotating band seat --------------
103.
Visual (see 3.5)
Depth of knurling, min. ---------------------------
104.
Visual
Minor:
Diameter, rotating band seat, knurled -------------
201.
Gage
Width, rotating band seat -------------------------
202.
Gage
Width, knurling, min. -----------------------------
203.
Visual
4.4.3.4
Body and rotating band assembly (see Dwg. D10542659)
Critical:
1. Ferrous metal discontinuity -----------------------
Soundness
7
