MIL-P-50601A(MU)
4.4.3.4 (Cont)
Method of Inspection
Categories and Defects
Major:
Length, mouth to rear of rotating band ------------
Gage
101.
Diameter, body rear of rotating band, min. --------
Gage
102.
Diameter, rotating band ---------------------------
Gage
103.
Width, rotating band -------------------------------
Gage
104.
Location, crimp groove ----------------------------
Gage
105.
Profile, crimp groove ----------------------------
Gage
106.
Radius, rear edge of crimp groove, max. -----------
Gage
107.
Depth, crimp lip to bottom of tracer cavity -------
Gage
108.
Runout, rotating band, with datum surface ---------
Gage
109.
Diameter, bourrelet, min. -------------------------
Gage
110.
Diameter, body cavity -----------------------------
Gage
111.
Runout, body cavity with datum surface ------------
Gage
112.
Diameter, tracer cavity ---------------------------
Gage
113.
Runout, tracer cavity with datum surface ----------
Gage
114.
Diameter, metering disc cavity --------------------
Gage
115.
Depth, metering disc cavity -----------------------
Gage
116.
Width, crimp lip ---------------------------------
Gage
117.
Gage
Runout, metering disc cavity with datum surface ---
118.
Perforation or fracture in tracer cavity ----------
Visual
119.
Minor:
Outside diameter, mouth end -----------------------
Gage
201.
202.
Depth and width of undercut, front and rear of
rotating band ------------------------------------
Gage
Overall length -----------------------------------
Gage
203.
Foreign matter ------------------------------------
Visual
204.
Finish improper ----------------------------------
Visual
205.
Body (coated, prior to painting)
(see Dwg. D10542659)
4.4.3.5
Critical:
None defined.
Major:
Pitch diameter, thread ---------------------------- Gage
101.
Runout, thread with datum surface ----------------- Gage
102.
Minor:
Minor diameter, thread ---------------------------- Gage
201.
Length, complete thread, min. --------------------- Gage
202.
8
