MIL-DTL-46610F
Drawing Number
Paragraph
Title
Cup 1/
2/
4.4.2.2
Sheet 2 of 2
Next Higher
(continued)
Assembly
Conformance Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
Minor
Bad bevel
201
Level II
3.2
Visual
202
Brass Shavings
Level II
3.2
Visual
203
Cracked
Level II
3.2
Visual
Crooked or eared
204
Level II
3.2
Visual
205
Flat on crowned cup (where applicable) Level II
3.2
Visual
Crowned on flat cup (where applicable) Level II
206
3.2
Visual
Laminated metal
207
Level II
3.2
Visual
208
Ringed
Level II
3.2
Visual
209
V or U
Level II
3.2
Visual
210
Low cup
Level II
3.2
Visual
Note
1/. Refer to ORD-SIP-S314 for visual defect standards. In the event of conflict between this
specification and ORD-SIP-S314 as to defect classification, the classification specified in this
specification apply.
2/. 6006156, 9378276, 10524200, 10534927, 11820451, 7553772, 8597284, 10521997, 8597567,
12977196, 6000501, 10523084, 7639487, 5502646, 6006152, 9342868, 10523632, 10542379,
8597555, 10521998, 7553707, 8597283, 6000503, 10523085, 7635291, 7553097, 8658516.
