MIL-DTL-46610F
Paragraph
Title
Drawing Number
Primer 1/
2/
4.4.2.1
Sheet 1 of 1
Next Higher
Assembly
Conformance Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
Critical
None defined
Major
101
No anvil
100%
3.2
Visual
102
Double Anvil
100%
3.2
Visual
103
No charge
100%
3.2
Visual
104
Double or multiple foil - where
Level V
3.2
Visual
applicable
105
Slipped foil - where applicable
Level IV
3.2
Visual
106
Inverted or sideways inserted anvil
100%
3.2
Visual
107
Crushed or mutilated
Level V
3.2
Visual
108
Deep seated anvil
Level IV
3.2
Visual
109
Low anvil
Level IV
3.2
Visual
110
Loose anvil
Level V
3.2
Visual
111
Stained or corroded metallic
Level V
3.2
Visual
components
Note
1/. Refer to ORD-SIP-S314 for visual defect standards. In the event of conflict between this
specification and ORD-SIP-S314 as to defect classification, the classification specified in this
specification apply.
2/. 5001168, 5033178, 7645332, 10534279, 8594094, 10522621, 10535489, 7645336, 7645339,
8861197, 10522382, 10522383, 10522388, 10535491.
9
