MIL-DTL-46610F
7635291
-
Cartridge, Caliber .45, Ball, M9 (Steel Case)
7553097
-
Cartridge, Caliber .45, Ball, M33
(Copies of these drawings are available from U.S. Army ARDEC, ATTN: RDAR-EIS-PE,
Picatinny, NJ 07806-5000, or email pica.drawing.request@conus.army.mil.)
2.3 Order of precedence. Unless otherwise noted herein or in the contract, in the event of
a conflict between the text of this document and the references cited herein, the text of this
document takes precedence. Nothing in this document, however, supersedes applicable laws and
regulations unless a specific exemption has been obtained.
3. REQUIREMENTS
3.1 First article. When specified (see 6.2), a sample shall be subjected to first article
inspection in accordance with 4.3.
3.2 Conformance inspection. A sample of the completed primers shall be subjected to
conformance inspection in accordance with 4.4.
3.3 Components and assemblies. The components and assemblies shall comply with all
requirements specified in the applicable specifications and drawings.
3.3.1 M82 percussion primer (When assembled in the cartridge, 7.62mm. NATO, Ball.
M80). When No. 34 primer is made in accordance with Dwg. 10522621 for the M82 percussion
primer, it shall meet the requirements of this drawing when tested in the cartridge, 7.62mm.
NATO, Ball. M80.
3.4 Sensitivity. The sensitivity shall be in accordance with the limits specified in Table I
for each type of primer:
TABLE I. Primer sensitivity limits
Height in Inches
Primer
Required Case
(H+5s fire)
(H-2s no-fire)
Dwg. No. 10522621
7.62mm Match
15
3
Dwg. No. 10535489
7.62mm Match
15
3
Dwg. No. 10522621
7.62mm
15
3
Dwg. No. 8594094
7.62mm Match
15
3
Dwg. No. 10522621
7.62mm Grenade
15
3
Dwg. No. 10522621
7.62mm Blank
15
3
Dwg. No. 10535489
7.62mm Blank
15
3
Dwg. No. 7645332
Caliber .30 Blank
15
2½
Dwg. No. 8594094
Caliber .30 Blank
15
2½
Dwg. No. 7645336
Caliber .45
16
2½
Dwg. No. 5001168
Caliber .45
16
2½
Dwg. No. 7645339
Caliber .50
15
2½
Dwg. No. 5033178
Caliber .50
15
2½
Dwg. No. 7645336
Caliber .45 Blank
18
3
Dwg. No. 5001168
Caliber .45 Blank
18
3
4
