MIL-DTL-46610F
Paragraph
Title
Drawing Number
1/
4.4.2.6
Gaging Primer
Sheet 1 of 1
Next Higher
Assembly
Conformance Requirement Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
Critical
None defined
Major
101
Diameter
Level III
3.2
Gauge
102
Excessive difference between long and
Level III
3.2
Gauge
short axis diameters, where applicable.
Minor
201
Height
Level II
3.2
Gauge
Note
1/. 6006156, 9378276, 10524200, 10534927, 11820451, 7553772, 8597284, 10521997, 8597567,
12977196, 6000501, 10523084, 7639487, 5502646, 6006152, 9342868, 10523632, 10542379,
8597555, 10521998, 7553707, 8597283, 6000503, 10523085, 7635291, 7553097, 8658516.
4.4.3 Tests. The tests listed in Table VIII shall be conducted as specified in 4.5.
4.4.3.1 Class 1 primers (see 1.2). Each lot of class 1 primers: shall be subjected to all the
tests listed in Table VIII.
4.4.3.2 Class 2 primers. Each lot of class 2 primers shall be subjected to only the priming
composition and sensitivity tests listed in Table IX. A reduced inspection level may be applied
for priming composition in accordance with note 4 of Table VIII.
4.4.3.3 Test samples. The quantities for the various tests shall be as specified in Table
VIII. Only primers having met the visual and dimensional requirements shall be used in the
ballistic tests, and shall have been selected in such a manner that the sample is representative of
the entire lot. The primers selected shall be thoroughly mixed before being divided into samples
for the various tests.
15
